WiFi Bluetooth Cloud USB Print Server – Convert USB Printers to Wireless, Cloud & Remote Printing with API MQTT
Model: LY-CPS-WB07 Cloud WiFi Bluetooth Print Server
-
Instant Upgrade: Convert any USB printer into a WiFi, Bluetooth, or Cloud-enabled printer in seconds.
-
Powerful Performance: Built with industrial-grade ARM A7 1.2GHz chipset for faster, more stable printing.
-
Versatile Connectivity: 4-in-1 connection – Dual-Band Wi-Fi (2.4GHz/5GHz), RJ45 LAN, Cloud, and Bluetooth (SPP+BLE).
-
Printer Sharing: Multiple users can share one printer wirelessly, perfect for offices or home use.
-
Cloud Printing: Print remotely from anywhere—whether at home, in the office, or on a business trip.
-
Bluetooth Printing: Enables printing directly via Bluetooth without network connection.
-
Easy Setup: Lite version App and user-friendly PC Cloud CMS for quick configuration in seconds.
-
API & MQTT Integration: Supports third-party servers and private cloud customization for enterprise needs.
-
Broad Compatibility: Works with thermal, label, dot matrix, laser, and inkjet printers—no brand limitations.
-
Compact Design: Size 74×58×25mm, weight 57.3g, powered by 5V/1A.
Transform USB Printers into Wireless Cloud Printers for Multi-User, Remote, and LAN/Bluetooth Printing
LY-CPS-WB07 is a Wireless WiFi Network USB Print Server, a portable device that allows multiple users on a wireless network to share a single printer. Users can send print jobs anytime, anywhere via computer or smartphone, and place the printer wherever convenient, free from USB cable limitations.
It also functions as a Bluetooth Printer Adapter, instantly converting a USB printer into a Bluetooth printer. Even without a network connection, print jobs can be sent via Bluetooth from computers, smartphones, or PDAs.
Equipped with stable cloud server technology, LY-CPS-WB07 supports API integration and third-party MQTT servers. It solves printer connection issues and enables true remote printing, allowing users to send print jobs to office printers from home or on business trips.
1 USB Network Bluetooth WiFi Cloud Print Server Printer Server Adapter Highlights Selling Points
*Instant USB-to-Wireless Upgrade: Transform your USB printer into a wireless device in seconds with the LOYALTY-SECU WiFi Bluetooth Cloud Print Server—say goodbye to messy cables.
* Multiple Printing Options: Supports Wi-Fi (2.4GHz & 5GHz), LAN (RJ45), Bluetooth, and Cloud printing. Highly compatible with over 99.5% of printers on the market.
* Bluetooth Printing Anywhere: Share a USB printer with multiple users via Bluetooth, even without a network connection—just connect your printer to the Bluetooth print server.
* Quick & Easy Setup: Lite Version APP enables fast network access. User-friendly PC Cloud Printing CMS allows cloud printer setup in seconds.
* API & MQTT Integration: Compatible with third-party MQTT servers and supports custom private cloud solutions for reliable cloud printing.
* Perfect for Any Environment: Ideal for homes, small offices, schools, government, and institutions with multiple LAN offices needing shared printing.
Warm Reminder: LOYALTY-SECU Print Servers do not support printing from iPhone or iPad, and Bluetooth printing is not supported on Mac OS PCs.
Network Cloud Print Server Main Features
1. Revitalize Old USB Printer: Transform your old USB printer into wireless printers in seconds with the LOYALTY-SECU 1 USB WiFi Bluetooth Cloud Print Server.
2. Industrial-Grade Performance: Featuring an ARM A7 1.2GHz CPU, our print server supports the CUPS system and IPP printing protocol, delivering faster, more stable printing experiences and exceptional compatibility compared to other vendors.
3. With Cloud Printing Feature: Allows you to print to any printer via anytime anywhere using your phone or tablet or computer.
When the cloud print server is connected to the company printer, users can also print documents to the company printer from home or on a business trip.
4. Integrated Bluetooth and WiFi: Equipped with 2.4GHz and 5GHz WiFi and Dual Mode Bluetooth, enjoy the convenience of printing via WiFi or Bluetooth simultaneously.
5. Share a Multi-functional Cloud Printer: Comes with advanced and stable cloud server technology, it not only effectively solves the printer connection problem, but also solves the problem of remote printing, allowing file printing to be truly realized anytime and anywhere.
6.Versatile Printing Options: Enjoy the convenience of printing from both your smartphone and computer simultaneously. This Multifunctional printer server supports wired network, WiFi, Bluetooth, cloud printing, allowing you to choose the most convenient method.
7. Quick Configuration: Simplify the installation process with the Simple APP and Professional PC Cloud CMS. Connect and configure the cloud print server adapter easily using the Type-C cable for power supply and setup. It is compatible with various operating systems, including Windows, Mac OS, Linux, Android, and Harmony OS.
8. High Compatibility: Compatible with over 99.5% of printer models on the market, including inkjet, laser, label/barcode, dot matrix, thermal/receipt, and MFP printers.
9. Computer and Smartphone Print Sharing: Works with Windows 2000/2003/XP/Vista/7/8/10/11, MAC OS (MAC OS discovers printers automatically), LINUX systems. Easily share and print files from Android and Harmony OS devices, supporting various formats such as image, PDF, PPT, Excel, and Word.
10. Flexible Connectivity Options: Connect through wired network, WiFi, Bluetooth, Cloud Server,offering flexibility based on your working environment.
Cloud Printing – Breaking Geographical and Distance Barriers
The cloud print server operates on internet-based printing services, distinguishing it from traditional LAN printing methods. Once connected to a wide-area network (WAN), users can submit print tasks from anywhere, and printers around the world can receive and execute these tasks at any time, eliminating limitations of geography, region, or distance.
LOYALTY-SECU Print Servers Unsupported USB Printer Models
Canon:
Canon LBP Series Printers:
For Example : 2900/3000/3010/3018/3050/3100/3200/3210/3250//3300/3310//3410/6000/6200/6230/6300/7010/
7100/7200/7680/8780 etc.
EPSON:
EPSON R Series Printers:
For Example : Epson Stylus Photo R200/220/330/260/280/300/300M/320/330/340/380/800/R1800/1900/R2000/R2400/R2880/R3000, etc.
Epson Stylus Series Printers:
For Example: 300/400/800/800+/1000/1500, etc.
Epson Stylus Color Series: 880/880i/900/900G/900N/980/980N, etc.
Epson Stylus Pro Series: 3880/4000/4800/4880/4900/5000/5500, etc.
RICOH:
All Ricoh Printer Models (Excludes MP2014AD)
HP:
HP1022
VERY IMPORTANT
1.For LOYALTY-SECU Print Server Products, we recommend to the users who know little bit network setting.
2.LOYALTY-SECU Provide the technical remote-control service via TeamViewer or AnyDesk for Print Server Quick Configuration
3.Before using the print function, please download the Print Server APP, PC Cloud CMS and User Manual from our business site.
Workable Printer Types:
Inkjet Printers,Label Printer, Barcode Printer, Impact Printer (Dot Matrix Printing),Thermal Label or Receipt Printer, Laser Printer, Multifunction Printer (MFP), and so on.
Application Scenarios:
Small and medium-sized companies, schools, stock markets, education, express companies, and e-commerce companies are among those that employ professional network administrators.
Product Package Items:
1PCS* USB Print Server
1PCS* 5V/2A Power Adapter
1PCS* User Manual
Cloud WiFi Bluetooth Print Server Specification
|
Model |
LY-CPS-WB07 |
|
|
Product Item |
Wi-Fi Bluetooth |
|
|
CPU |
X1600E,1GHz Frequency,64MB DDR2,128MB Flash |
|
|
Interfaces |
Network |
802.3 100M Ethernet port |
|
Wi-Fi |
2.4GHz &5GHz, 802.11b/g/n/ac |
|
|
Bluetooth |
Bluetooth V2.1+EDR And BT 5.2 |
|
|
Support Printer |
Inkjet Printers,Label Printer, Barcode Printer, Impact Printer (Dot Matrix Printing), Thermal Label or Receipt Printer, Laser Printer, Multifunction Printer (MFP), and so on. |
|
|
Printing Method |
Cloud Printing |
PC Cloud Printing CMS (No software connection required on the PC, compatible with various software cloud printing) |
|
LAN Printing |
Standard LAN printing |
|
|
Bluetooth |
From Windows computer and Android smartphone. |
|
|
Wi-Fi Network |
Print Assitant APP |
|
|
Operating System |
LINUX |
|
|
USB Printer |
USB 1.1, USB 2.0 |
|
|
4G Function |
Available for Customization. |
|
|
Private |
Accept Private Cloud Printing Customization |
|
|
Network |
IPX, TCP/IP, NETBUEI, APPLETALK, LPR, SMB (Over TCP/IP) |
|
|
Working System |
Windows 2000/2003/XP/Vista/7/8/10/11 |
|
|
Product |
74*58*25mm |
|
|
Product Weight |
57.3g |
|
|
Packing Box Size |
13*8*3.2CM |
|
|
Packing Weight |
140g |
|
|
Power Supply |
5V/2A |
|
|
Packing Items |
1PCS * Print Server,1PCS * Power Adapter,1PCS * User Guide |
|
|
Product Color |
White, accept customization for product color |
|
|
Operating |
Temp: -10°C~50°C |
|
|
Charging |
Temp: 5°C~40°C , |
|
|
Storage |
Temp:-20°C~70°C, Humidity: 5%~95% |
|
